Installing and connecting the device
3.2 Mounting the device
SIMATIC IPC377G
Operating Instructions, 07/2022, A5E51366314-AB
29
3.2.3 Fastening a device using a VESA adapter
You can also fasten the SIMATIC IPC377G using a VESA (Video Electronics Standards
Association) adapter. Different models of VESA adapters are offered by third-party
manufacturers.
The following sizes of the SIMATIC IPC377G support VESA installation:
• 12" single-touch screen
• 15" single-touch screen
• 19" single-touch screen
• 22" single-touch screen
When fastening the VESA adapter, shock or vibration is not permitted.
Degree of protection for overall device
If you secure the device using a VESA adapter, degree of protection of the device will be
lost. Spray and water jets as well as penetrating substances can then damage the device.
Dimensioning of the VESA adapter
When selecting the VESA adapter, make sure that it is designed for at least four times the
The device must be mounted securely
Inadequately dimensioned fastening material may cause the device to fall down. Serious
bodily injury may result.
Make sure that fasteners are adequately dimensioned during installation of the device.
Make sure to consider the weight of the device and the forces acting on the device when
dimensioning the fasteners. This applies in particular to dynamic load of the device. All
fasteners including mounting surfaces, support arm systems, and fastening elements such
as screws must be able to carry at least four times the weight of the device.
Observe any further statutory specifications applying at the location of use of the device and
further applicable regulations with regard to the fastening of the device.
