Siemens SIMATIC IPC377G

Installing and connecting the device
3.1 Preparing for installation
SIMATIC IPC377G
22 Operating Instructions, 07/2022, A5E51366314-AB
3.1.3 Permitted mounting positions
The device may be mounted in the following positions:
• Standard position: Vertical installation in horizontal format
For vertical installation in horizontal format, the following ambient temperatures are
permitted:
Maximum ambient temperature at the device
Comment
12" and15"
19" and 22"
50 °C
45 °C
The device enclosure fulfills the requirement of
a fire protection enclosure.
• Inclined installation in horizontal format with a vertical inclination of maximum ±45 °
For inclined installation in horizontal format, the following ambient temperatures are
permitted:
Maximum ambient temperature at the device
Comment
12" and15"
19" and 22"
50 °C
45 °C
The device enclosure fulfills the requirement of
a fire protection enclosure.
