Siemens SIMATIC IPC677D User Manual

Technical information
8.4 Technical specifications
SIMATIC IPC677D
Operating Instructions, 09/2014, A5E32995420-AC
123
Display
15"
1
15"
2
19"
22"
Display type LCD TFT with
extended
viewing angle
LCD TFT LCD TFT LCD TFT with
extended
viewing angle
Active display area 331 x 207 mm 364 x 216 mm 410 x 230 mm 475 x 267 mm
Resolution 1280 x
800 pixels
1366 x 768
pixels
1366 x 768
pixels
1920 x 1080
pixels
Displayable colors
Up to 16.7 million
Brightness control Yes, value range 0 to 99
3
0 = backlighting off
Backlighting
Half Brightness Life Time
(MTBF
43
)
LED
80000 h
LED
70000 h
LED
50000 h
LED
30000 h
Pixel error class in accordance
with ISO 9241-307
I
Contact force resistive touch
screen
With test stylus, 2 mm diameter: 5 N
Power consumption
25 W
25 W
25 W
32 W
1
resistive touch screen only
2
capacitive touch screen only
3
Via SetBrightness dialog: 9 ... 99 (≙ 10 ... 100%),
via SetBrightness command line call: 0 ... 99
4
MTBF: Operating hours after which the maximum brightness is reduced by half compared to the
original value. MTBF is increased by using the integrated dimming function, for example, time-
controlled via screen saver or centrally via PROFIenergy.
Graphics
Graphic controller
• Xeon: Intel® HD Graphics Controller P4600 GT2
• Core i3: Intel® HD Graphics Controller P4600 GT2
• Celeron: Intel® HD Graphics Controller
Graphics memory
32 - 512 MB Shared Memory
Resolutions/frequencies
/colors
DVI-I: 640 × 480 to 1920 × 1200 / 60 Hz / 24 bit
DisplayPort: max. 3840 × 2160 / 130 Hz / 30 bit
