Operating the device and device functions
5.5 Extended device functions
SIMATIC IPC677D
60 Operating Instructions, 09/2014, A5E32995420-AC
SIMATIC IPC DiagBase software
Use the functions of the SIMATIC IPC DiagBase software included in the scope of delivery
for local monitoring. Use the "DiagBase Management Explorer" application to obtain a clear
overview for monitoring purposes. Use the DiagBase Alarm Manager to receive notifications
about individual alarms.
Note
For more information on SIMATIC IPC DiagBase software functionality, please refer to the
relevant online help.
SIMATIC IPC DiagMonitor software
SIMATIC IPC DiagMonitor is available on CD (not included in the scope of delivery). The CD
contains both the monitoring software and the software for the stations to be monitored. The
interface specifications and a library for creating your own applications are also provided.
Temperature monitoring/display
Four temperature sensors monitor the temperature of the device at several positions:
● Processor temperature
● Temperature close to the RAM ICs/chips
● Temperature of the basic module below the power supply
● Temperature in proximity of the air inlet
A temperature error is triggered under these circumstances:
● The configured low threshold for the temperature has been violated.
● The configured high threshold for the temperature has been violated.
A temperature error causes the following reaction:
The DiagBase or DiagMonitor software alerts the user.
The temperature error is retained in memory until temperatures have fallen below the
thresholds and it is reset by one of the following measures:
● Acknowledgment of the error message by the monitoring software
● Restart of the device
