8.4 Technical specifications
SIMATIC IPC677D
126 Operating Instructions, 09/2014, A5E32995420-AC
8.4.3
Current and power requirements
Maximum current values
Component
Voltage
+5 V
+3.3 V
+12 V
-12 V
Base device
1, 2
7.5 A
Hard disk drive 1 × 3.5"
2
0.6 A
0.5 A
Hard disk drives 2 × 2.5"
2
1.2 A
DVD burner drive
2
0.8 A
USB ports
3 4
2 A
PCI/PCIe slots
4
total
Maximum per PCI slot
Maximum per PCIe slot
4 A
4 A
-
6 A
6 A
6 A
2 A
0.5 A
2 A
0.1 A
0.1 A
-
Internal front interfaces for Panel PC
2.41 A
Individual currents (max. permissible)
5
10 A
10 A
12.5 A
0.3 A
1
Base device includes motherboard, processor, memory, both fans, CF
2
Depends on the selected device configuration
3
2 × USB3.0 high current and 2 × USB2.0 low current.
4
The total power for individual PCI/PCIe slots cannot exceed 25 W.
The total power for USB and PCI/PCIe slots cannot exceed 30 W.
5
The max. permitted accumulated power of +5 V and +3.3 V is 60 W.
Typical power values
Component
Current consumption
230 VAC
Current consumption
24 VDC
Power consumption
0.85 efficiency
Base device
0.3 A
3.0 A
70 W
Hard disk drive 1 × 3.5"
0.04 A
0.38 A
9 W
Hard disk drives 2 × 2.5"
0.03 A
0.25 A
6 W
DVD burner drive
0.02 A
0.17 A
4 W
USB ports
max. 0.06 A
max. 0.54 A
max. 13 W
PCI/PCIe slots
0.16 A max.
1.54 A max.
Max. 37 W
Operator panel
max 0.14 A
max. 1,33 A
max. 32 W
