Maintaining and servicing your device
7.7 Removing and installing hardware
SIMATIC IPC677D
94 Operating Instructions, 09/2014, A5E32995420-AC
Procedure
1.
Open the battery compartment with
a screwdriver at the indicated loc
a-
tion.
2.
Remove the battery holder.
3.
Detach the cable.
4.
Remove the old battery.
5.
Fasten the new battery and reinsert the battery holder.
6.
Close the battery compartment.
