Siemens SIMATIC KTP400 Basic - Design of KTP400 Basic HMI Device

Overview
1.2 Design of the KTP400 Basic HMI device
KTP400 Basic, KTP600 Basic, KTP1000 Basic, TP1500 Basic
12 Operating Instructions, 08/2008, A5E01075587-01
1.2 Design of the KTP400 Basic HMI device










① Recesses for mounting clamps ⑥ Connection for functional ground
② Display / touch screen ⑦ PROFINET interface
③ Mounting seal ⑧ Power supply connector
④ Guide for labeling strips ⑨ Rating plate
⑤ Function keys ⑩ Interface name
