Operating the user interface
4.2 General functions of the screen keyboard
KTP400 Basic, KTP600 Basic, KTP1000 Basic, TP1500 Basic
Operating Instructions, 08/2008, A5E01075587-01
43
4.2 General functions of the screen keyboard
The following keys are available on the screen keyboard of all Basic HMI devices:
Cursor left
Cursor right
Delete character
Cancel input
Confirm input
Display infotext. This key only appears when an infotext has been configured for the
operator control.
