Overview
1.6 Design of the KTP1000 PN Basic HMI device
KTP400 Basic, KTP600 Basic, KTP1000 Basic, TP1500 Basic
16 Operating Instructions, 08/2008, A5E01075587-01
1.6 Design of the KTP1000 PN Basic HMI device


① Display / touch screen ⑦ Rating plate
② Recesses for mounting clamps ⑧ DIP switch
③ Mounting seal ⑨ Interface name
④ Function keys ⑩ Connection for functional ground
⑤ PROFINET interface ⑪ Guides for labeling strips
⑥ Power supply connector

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Siemens SIMATIC KTP400 Basic and is the answer not in the manual?

Siemens SIMATIC KTP400 Basic Specifications

General IconGeneral
Display TypeTFT LCD
Display Resolution480 x 272 pixels
Supply Voltage24 V DC
Display Size4.3 inches
TouchscreenYes
InterfacePROFINET
Protection ClassIP65
Operating Temperature0 to 50 °C
Storage Temperature-20°C to 60°C
Communication InterfacePROFINET
MountingPanel Mount
