Overview
1.3 Design of the KTP600 DP Basic HMI device
KTP400 Basic, KTP600 Basic, KTP1000 Basic, TP1500 Basic
Operating Instructions, 08/2008, A5E01075587-01
13
1.3 Design of the KTP600 DP Basic HMI device


① Display / touch screen ⑦ Power supply connector
② Recesses for mounting clamps ⑧ Rating plate
③ Mounting seal ⑨ Interface name
④ Function keys ⑩ DIP switch
⑤ RS-422/485 interface ⑪ Guide for labeling strips
⑥ Connection for functional ground
