Overview
1.8 Product package
KTP400 Basic, KTP600 Basic, KTP1000 Basic, TP1500 Basic
18 Operating Instructions, 08/2008, A5E01075587-01
1.8 Product package
Product package
The following components are included in the product package of the HMI device.
Name Figure Quantity
HMI device 1
Installation instructions 1
Mounting seal 1
5 KTP400 Basic
8 KTP600 Basic
12 KTP1000 Basic
Clamps with stud bolts
14 TP1500 Basic
Mains terminal 1

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Siemens SIMATIC KTP400 Basic and is the answer not in the manual?

Siemens SIMATIC KTP400 Basic Specifications

General IconGeneral
Display TypeTFT LCD
Display Resolution480 x 272 pixels
Supply Voltage24 V DC
Display Size4.3 inches
TouchscreenYes
InterfacePROFINET
Protection ClassIP65
Operating Temperature0 to 50 °C
Storage Temperature-20°C to 60°C
Communication InterfacePROFINET
MountingPanel Mount
