Technical specifications
8.8 Specifications
KTP400 Basic, KTP600 Basic, KTP1000 Basic, TP1500 Basic
Operating Instructions, 08/2008, A5E01075587-01
93
8.8 Specifications
8.8.1 Specifications of the KTP400 Basic and KTP600 Basic
Weight
KTP400 Basic
Mono PN
KTP600 Basic
Mono PN
KTP600 Basic Color
DP
KTP600 Basic Color
PN
Weight without packaging Approx. 320 g Approx. 1070 g
Display
KTP400 Basic
Mono PN
KTP600 Basic
Mono PN
KTP600 Basic
Color DP
KTP600 Basic
Color PN
Type LCD mono FSTN LCD TFT
Display area, active 76.79 mm x 57.59 mm
(3.8")
115.2 mm x 86.4 mm
(5.7")
Resolution, pixels 320 x 240
Colors, displayable 4 grayscales 256
Contrast control Yes No
Backlighting
Half brightness life time,
typical
LED
30,000 h
CCFL
50,000 h
Input device
KTP400 Basic
Mono PN
KTP600 Basic
Mono PN
KTP600 Basic
Color DP
KTP600 Basic
Color PN
Type Touch screen, analog resistive
Function keys 4 6
Labeling strips Yes
Memory
KTP400 Basic
Mono PN
KTP600 Basic
Mono PN
KTP600 Basic
Color DP
KTP600 Basic
Color PN
Application memory 512 KB

Siemens SIMATIC KTP400 Basic Specifications

General

Display Type	TFT LCD
Display Resolution	480 x 272 pixels
Supply Voltage	24 V DC
Display Size	4.3 inches
Touchscreen	Yes
Interface	PROFINET
Protection Class	IP65
Operating Temperature	0 to 50 °C
Storage Temperature	-20°C to 60°C
Communication Interface	PROFINET
Mounting	Panel Mount
