Siemens SIMATIC KTP400 Basic User Manual

Technical specifications
8.8 Specifications
KTP400 Basic, KTP600 Basic, KTP1000 Basic, TP1500 Basic
Operating Instructions, 08/2008, A5E01075587-01
95
8.8.2 Specifications of the KTP1000 Basic and TP1500 Basic
HMI device
KTP1000 Basic Color DP KTP1000 Basic Color PN TP1500 Basic Color PN
Weight without packaging Approx. 2.65 kg Approx. 4.2 kg
Display
KTP1000 Basic Color DP KTP1000 Basic Color PN TP1500 Basic Color PN
Type LCD TFT
Display area, active 211.2 mm x 158.4 mm
(10.4")
304.1 mm x 228.1 mm
(15")
Resolution, pixels 640 x 480 1024 x 768
Colors, displayable 256
Brightness control Yes
Backlighting
Half brightness life time, typical
CCFL
50,000 h
Input device
KTP1000 Basic Color DP KTP1000 Basic Color PN TP1500 Basic Color PN
Type Touch screen, analog resistive
Function keys 8 function keys No
Labeling strips Yes No
Memory
KTP1000 Basic Color DP KTP1000 Basic Color PN TP1500 Basic Color PN
Application memory 1024 KB
Interfaces
KTP1000 Basic Color DP KTP1000 Basic Color PN TP1500 Basic Color PN
1 x RS 422/RS 485 Max. 12 Mbps -
1 x Ethernet - RJ45 10/100 Mbps

Siemens SIMATIC KTP400 Basic Specifications

General

Display Type	TFT LCD
Display Resolution	480 x 272 pixels
Supply Voltage	24 V DC
Display Size	4.3 inches
Touchscreen	Yes
Interface	PROFINET
Protection Class	IP65
Operating Temperature	0 to 50 °C
Storage Temperature	-20°C to 60°C
Communication Interface	PROFINET
Mounting	Panel Mount
