Siemens SIMATIC NET CP 443-1 Advanced User Manual

Documentation references
A.2 On installing and commissioning the CP
CP 443-1 Advanced (GX30)
Manual, 03/2019, C79000-G8976-C256-05
119
A.2
On installing and commissioning the CP
A.2.1
/7/
SIMATIC S7
Automation System S7-400, M7-400
Siemens AG
● Installation: Installation manual
Link: (https://support.industry.siemens.com/cs/ww/en/view/1117849)
● Module Data: Reference Manual
Link: (https://support.industry.siemens.com/cs/ww/en/view/1117740)
● CPU data: Device Manual
Link:
A.3
For configuration with STEP 7 / NCM S7
A.3.1
/8/
SIMATIC NET
Commissioning PC Stations - Manual and Quick Start
Configuration Manual
Siemens AG
Link: (https://support.industry.siemens.com/cs/ww/en/ps/15362/man)
A.3.2
/9/
SIMATIC
Configuring Hardware and Connections with STEP 7
Siemens AG
Part of the documentation package "STEP 7 Basic Knowledge"
(Part of the online documentation in STEP 7)
Link: (https://support.industry.siemens.com/cs/ww/en/view/45531110)
A.3.3
/10/
Automatisieren mit STEP 7 in AWL und SCL (ISBN: 978-3-89578-280-0) /
Automating with STEP 7 in STL and SCL (ISBN: 978-3-89578-295-4)
User manual, programming manual
Berger, Hans
Publicis KommunikationsAgentur GmbH, GWA, 2006

Siemens SIMATIC NET CP 443-1 Advanced Specifications

General

Product type designation	CP 443-1 Advanced
Compatibility	SIMATIC S7-400
Supply voltage	24 V DC
Number of ports	2
Interfaces	Ethernet, Serial
Ethernet	10/100 Mbps
Degree of protection	IP20
Weight	0.5 kg
Type	Communications processor
Product Type	Communication Processor
Protocols Supported	TCP/IP, UDP, ISO on TCP
Serial interface	RS232/RS485
Operating Temperature	0 to 60 °C
Mounting	Rack mounting
Number of Connections	Up to 16
