Requirements for use
3.3 Project engineering
CP 443-1 Advanced (GX30)
Manual, 03/2019, C79000-G8976-C256-05
45
Project engineering
Configuration and downloading the configuration data
It is possible to download the configuration data to the CP via MPI or LAN/Industrial
Ethernet. Downloading is possible over the PROFINET or the gigabit interface of the CP.
You require STEP 7 with additional modules in the following version:
Table 3- 1 Required STEP 7 version
STEP 7 version (either V5.5 with “SCT“ or Professional)
CP 4431 Advanced functionality
• STEP 7 V5.5 + Service Pack 4 + HF 8
You also require the following:
• HSP 1105 (Hardware Update)
• Program block library "SIMATIC NET CP" version V5.5.4
• Security Configuration Tool (SCT) V4.1
SCT is used in the configuration of the security function from
within STEP 7.
The full functionality as described in this
document can be used.
STEP 7 Professional V13 The following are not supported:
• PROFINET CBA
• Innovations of firmware version V3.2
You will find the HSP on the Internet pages of Siemens Industry Online Support at the
following address:
Link: (https://support.industry.siemens.com/cs/ww/en/view/23183356)
You will find the program block library on the Internet pages of Siemens Industry Online
Support at the following address:
Link: (https://support.industry.siemens.com/cs/ww/en/view/109481127)
You will find the SCT on the STEP 7 DVD.
Configuration for use of PROFINET CBA
To be able to work in the PROFINET CBA environment, you require the SIMATIC iMap
engineering tool.
SIMATIC iMap requires a connection via Industrial Ethernet (TCP/IP protocol). The following
SIMATIC iMap configuration software is required:
Table 3- 2 Required SIMATIC iMap version
CP 4431 Advanced functionality
as of V3.0 + Service Pack 3 The full functionality of the device can be used as of hard-
ware version 1 and firmware version V3.0.
