CP 443-1 Advanced (GX30)
Manual, 03/2019, C79000-G8976-C256-05
13
Properties of the CP
Application
The CP is intended for use in an S7400 or S7400H (faulttolerant) automation system. It
allows the S7400 / S7400H to be connected to Industrial Ethernet.
With a combination of different security measures such as firewall, NAT/NAPT routers and
VPN (Virtual Private Network) over IPsec tunnels, the CP protects individual S7-400 stations
or even entire automation cells from unauthorized access.
The CP has the following interfaces:
● PROFINET interface (Ethernet interface)
A 4-port switch with IRT capability and with autocrossing, autonegotiation and
autosensing is integrated in the CP. The 4-port switch allows the integration of the CP in
a bus or a ring with media redundancy.
Each port of the switch is designed for simple diagnostics and is equipped with a
combined RXD/TXD / LINK dual LED. For special situations, each port can also be set to
a fixed mode manually using STEP 7, for example 10 or 100 Mbps half duplex / full
duplex.
● Gigabit interface with security access
The CP also has an Ethernet interface complying with the gigabit standard IEEE 802.3ab.
This is independent of the PROFINET interface and supports autocrossing,
autonegotiation and autosensing. The gigabit interface can, for example, be used to
connect to a PG/PC or to a higherlevel company network.
The gigabit interface allows a secure connection to external networks via a firewall and
VPN. The CP provides the following protective function:
– Protection of the S7-400 station in which the CP is operated.
– Protection of the internal company networks connected to the PROFINET interface.
Each port can be disabled individually in the configuration.
Note
The following servic
es or characteristics are only available on the PROFINET interface:
PROFINET
Programmed communications connections (program block IP_CONFIG).
