Performance data
2.6 Characteristic data for PROFINET CBA
CP 443-1 Advanced (GX30)
30 Manual, 03/2019, C79000-G8976-C256-05
If one of the limit values specified for the interconnections is exceeded, they cannot be
downloaded to the module. When the interconnections are downloaded, the SIMATIC iMap
configuration tool generates an error message to this effect. If a limit value relating to the
number or size of components is exceeded, the CPU will not change to RUN!
Number of remote interconnection
32 64
Total of all attachments 600 600
Data length of all incoming attach-
3200 bytes 8192 bytes 1452 bytes
Data length of all outgoing attach-
3200 bytes 8192 bytes 1452 bytes
Data length for arrays and structures
(acyclic interconnections), maximum
2048 bytes 8192 bytes
*)
1452 bytes
Data length for arrays and structures
(cyclic interconnections), maximum
250 bytes 250 bytes 250 bytes
Data length for arrays and structures
(local interconnections), maximum
- 2400 bytes 1452 bytes
Remote interconnections with acyclic transmission
Scanning frequency: Scanning inter-
val, min.
Selectable values: 100, 200, 500 and
fast value: 20%
medium value: 40%
slow value: 40%
100 ms minimum
Number of incoming interconnections
Number of outgoing interconnections
Data length of all incoming intercon-
2048 bytes 8192 bytes 1452 bytes
Data length of all outgoing intercon-
nections
2048 bytes 8192 bytes
Remote interconnections with cyclic transmission
Transmission frequency: Transmission
interval, min.
Selectable values: 8, 16, 32, 64, 128,
fast value: 20%
medium value: 40%
slow value: 40%
8 ms minimum
Number of incoming interconnections
Number of outgoing interconnections
