Siemens SIMATIC NET CP 443-1 Advanced User Manual

Requirements for use
3.5 Programming
CP 443-1 Advanced (GX30)
Manual, 03/2019, C79000-G8976-C256-05
47
Using program blocks for the SEND/RECEIVE interface
For data transfer on the SEND/RECEIVE interface, there are program blocks for short and
long blocks of data.
For fast data transmission up to a data length of 1452 bytes, the SPEED SEND/RECEIVE
program blocks AG_SSEND (FC53) and AG_SRECV (FC63) are supported.
Functionality
Requirement
Transfer of data fields <= 240 bytes
• You require the program blocks AG_SEND (FC5) and
AG_RECV (FC6) or alternatively the program blocks
AG_LSEND (FC50) and AG_ LRECV (FC60).
Transfer of blocks of data > 240 bytes to <= 8192 bytes
*)
• You require the program blocks AG_LSEND (FC50) and
AG_LRECV (FC60).
Accelerated transfer of blocks of data <= 1452 bytes
• You require the program blocks AG_SSEND (FC53) and
AG_SRECV (FC63).
*)
The length depends on the protocol
Note
Multicomputing mode
Note that in multicomputing mode, communication using SPEED
SEND/RECV is possible
only via the CP assigned to the CPU.
Note
Operation with a high communication load
Note the recommendations in section
Recommendation for use with a high communications
load
(Page 80) for operation with a high communications load.

Siemens SIMATIC NET CP 443-1 Advanced Specifications

General

Product type designation	CP 443-1 Advanced
Compatibility	SIMATIC S7-400
Supply voltage	24 V DC
Number of ports	2
Interfaces	Ethernet, Serial
Ethernet	10/100 Mbps
Degree of protection	IP20
Weight	0.5 kg
Type	Communications processor
Product Type	Communication Processor
Protocols Supported	TCP/IP, UDP, ISO on TCP
Serial interface	RS232/RS485
Operating Temperature	0 to 60 °C
Mounting	Rack mounting
Number of Connections	Up to 16
