Installation and commissioning
5.3 Commissioning
CP 443-1 Advanced (GX30)
Manual, 03/2019, C79000-G8976-C256-05
59
Follow the steps outlined below:
1. Download the configuration data from your STEP 7 project to the S7400 station.
Requirement: You have configured the CP in a STEP 7 project for the properties and
services you want to use.
You can connect the PG when configuring the CP as follows:
– Via MPI
– Via Industrial Ethernet
For further details, refer to the general part /2/ (Page 118) of this manual:
– For initial addressing (node initialization)
– For downloading the defined configuration
The PG / PC requires a LAN attachment, for example via a CP 1613 or CP 1411 and
must have the necessary software (for example the S71613 package or SOFTNET IE).
The TCP/IP protocol or ISO protocol must be installed. The protocol used must then be
applied to the S7ONLINE access point.
2. Use the diagnostics functions during commissioning and to analyze problems.
You will find an overview of the options in the section Diagnostics options (Page 95).
3. Optional when using with PROFINET CBA:
Download the PROFINET CBA component using SIMATIC iMap.
If the S7 station in which the CP is operated is used as a PROFINET CBA component,
the interconnections are downloaded using SIMATIC iMap; with standard components,
programs and configuration data are also downloaded with SIMATIC iMap.
For more detailed information, refer to the section Using the CP for PROFINET CBA
(Page 87).
Note
Module replacement - adapting the cycle load with an older CPU
If you use the CP as a replacement (for example for a CP
443–1 "GX11") w
ith an older CPU,
the default communication load setting of 20% for the CPU can lead to overload. In this
case, you should set the communication load for the CPU in STEP
7 (parameter "Scan cycle
load from communication") to a lower value
- for example 10%.
With CPUs as of version V5.1, changing the setting is unnecessary.
