Configuring with Web Based Management
5.5 "System" menu
SCALANCE W760/W720 to IEEE 802.11n Web Based Management
122 Configuration Manual, 11/2014, C79000-G8976-C350-03
The table has the following columns:
●
Shows the file type.
●
Shows the short description of the file type.
●
With this button, you can upload files to the device. The button can be enabled, if this
function is supported by the file type.
●
With this button, you can save files from the device. The button can only be enabled if
this function is supported by the file type and the file exists on the device.
●
With this button, you can delete files from the device. The button can only be enabled if
this function is supported by the file type and the file exists on the device.
Note
Following a firmware update, delete the cache of the Web browser.
Procedure
Loading files using HTTP
1. Start the load function by clicking the one of the "Load" buttons.
The dialog for loading a file opens.
2. Go to the file you want to load.
3. Click the "Open" button in the dialog.
The file is now loaded.
Whether or not a restart is necessary, depends on the loaded file. If a restart is necessary, a
message to this effect will be output. Other files are active and executed immediately, for
example the CLI script file.
1. After loading, restart the device. The changes only take effect a restart.
1. Start the save function by clicking the one of the "Save" buttons.
2. You will be prompted to select a storage location and a name for the file. Or you accept
the proposed file name. To make the selection, use the dialog in your browser. After
making your selection, click the "Save" button.
Deleting files using HTTP
1. Start the delete function by clicking the one of the "Delete" buttons.
The file will be deleted.
Reusing configuration data
