Configuring with Web Based Management
5.4 "Information" menu
SCALANCE W760/W720 to IEEE 802.11n Web Based Management
84 Configuration Manual, 11/2014, C79000-G8976-C350-03
Overview AP
Overview of the configuration
This page shows these settings/properties of the WLAN or the WLAN interface.
Note
This tab is available only in access point mode.
Table 1 has the following columns:
●
Shows the available WLAN interfaces.
●
Shows the transmission standard. If DFS is activated, the transmission standard
"802.11h" is not shown additionally but only the configured transmission standard
"802.11a".
●
Shows the configured channel. If "Auto" is displayed, the access point searches for a free
channel itself.
●
If the DFS function is enabled, the configured alternative channel of the access point is
displayed.
If "Auto" is displayed, the access point searches for an alternative channel itself.
If the DFS function is activated and the access point browses for primary users for 60
seconds before starting communication with the selected channel, the text "scanning ..."
is displayed instead of the channel.
●
Shows the channel of the access point via which the access point communicates.
