Siemens SIMATIC NET SCALANCE W760 Series User Manual

Configuring with Web Based Management
5.5 "System" menu
SCALANCE W760/W720 to IEEE 802.11n Web Based Management
Configuration Manual, 11/2014, C79000-G8976-C350-03
119
5.5.7
Load&Save
Overview of the file types
Table 5- 1 HTTP
File type
Down-
load
Save
Delete
Config
Start configuration
X
X
--
ConfigPack Detailed configuration information. for example,
start configuration, users, certificates
X X --
CountryList
The zip file contains the country list as a csv and as
a pdf file.
-- X --
Debug
This file contains information for Siemens Support.
--
X
X
Firmware
Firmware
X
--
--
GSDML
Information on the device properties
--
X
--
HTTPS Cert
HTTPS certificate
X
--
X
LogFile
File with entries from the event log table
--
X
--
MIB
Private MSPS MIB file "Scalance_w_msps.mib"
--
X
--
Script
CLI script file
X
--
--
StartupInfo
Startup log file
--
X
--
Users
File with user names and passwords
X
X
--
WLANAuthlo
g
File with entries from the WLAN Authentication Log
(information on successful or failed authentication
attempts)
-- X --
WLANCert
(in client
mode only)
User certificate. You can specify a password for the
user certificate on the WBM page "Load&Save >
Password".
X X X
WLANServC
ert
(in client
mode only)
Server certificate. X -- X
WLANSigRe
c
(in client
mode only)
The zip file contains the following:
• csv file with the measured values of the signal
recorder
• pdf file with the measured values and an addi-
tional graphic representation of the measured
values.
You will find information about the measured val-
ues and their graphic representation in the section
"Signal Recorder (Page 193)".
-- X X
