Configuring with Web Based Management
5.9 "Security" menu
SCALANCE W760/W720 to IEEE 802.11n Web Based Management
Configuration Manual, 11/2014, C79000-G8976-C350-03
229
The table has the following columns:
●
Shows the available WLAN interfaces.
●
Enter the WEP key or the AES key.
For the WEP key, characters of the ASCII code from 0x20 to 0x7E or hexadecimal
characters from 0x00 to 0xFF are permitted.
If iPCF or iPCF-MC mode is enabled, only the encryption method AES with 128-bit key
length is supported.
You can choose between the following key lengths:
– 5 or 13 ASCII or 10 or 26 hexadecimal characters (40/104 bits)
– 16 ASCII or 32 hexadecimal characters (128 bits)
Note
The hexadecimal characters are entered without being preceded by "0x".
One
hexadecimal character codes four bits. The entries "ABCDE" (ASCII characters) and
"4142434445" (hexadecimal characters) are therefore the same because the ASCII
character "A" has hexadecimal code "0x41".
●
Confirm the WEP key.
1. Enter at least one WEP key.
2. Click the "Set Values" button.
Management ACL
Description of configuration
On this page, you can increase the security of your device. To specify which station with
which IP address is allowed to access your device, configure the IP address or an entire
address range.
You can select the protocols and the ports of the station with which it is allowed to access
the device. You define the VLAN in which the station may be located. This ensures that only
certain stations within a VLAN have access to the switch.
