Configuring with Web Based Management
5.6 "Interfaces" menu
SCALANCE W760/W720 to IEEE 802.11n Web Based Management
Configuration Manual, 11/2014, C79000-G8976-C350-03
187
With Table 2, you can enable or disable all check boxes of a column of Table 3 (Data Rate)
at once. Table 2 has the following columns:
●
Shows that the setting is valid for all entries of Table 3.
●
In the drop-down list, select the setting for all entries. If "No Change" is selected, the entry
in Table 3 remains unchanged.
●
If you click the button, the setting is adopted for all entries of Table 3.
Table 3 (Data Rate) consists of the following columns:
●
Specifies the WLAN interface to which the information relates.
●
Shows the supported data transmission speeds in megabits per second.
●
Enable the option to assign the required data transmission speed to the WLAN interface.
Note
You need to enable at least one data transmission speed.
●
Enable the option to declare the required data transmission speed as "Basic". The "Basic"
parameter specifies that a client must be capable of this speed to be able to connect to
the access point. The "Basic" option can only be enabled if an available data transmission
speed has been selected.
Note
At least one data transmission speed needs to be specified as "Basic".
The "Default Values" button sets the selection of the values in compliance with the standard.
Procedure
To configure a certain data transmission speed on WLAN 1:
1. Enable the "Use selected data rates only" option for "WLAN 1".
2. From the "Radio" drop-down list, select the entry "WLAN 1".
3. Select the check box in the "Enabled" and in the "Basic" column for the required data
transmission speed.
4. Click the "Set Values" button.
:
1. Click the "Default Values" button. The selection is reset to the default setting.
