Siemens SIMATIC NET SCALANCE W760 Series User Manual

Configuring with Web Based Management
5.4 "Information" menu
SCALANCE W760/W720 to IEEE 802.11n Web Based Management
Configuration Manual, 11/2014, C79000-G8976-C350-03
91
Description
●
Radio
Shows the available WLAN interfaces in this column.
●
WLAN mode
Shows the transmission standard.
●
MAC Mode
Shows how the MAC address is assigned to the interface.
– Automatic
The client automatically adopts the source MAC address of the first frame that it
receives over the Ethernet interface.
– Manual
The address was entered manually.
– Own
The client uses the MAC address of the Ethernet interface for the WLAN interface.
– Layer 2 Tunnel
The client uses the MAC address of the Ethernet interface for the WLAN interface.
The network is also informed of the MAC addresses connected to the Ethernet
interface of the client. Up to 4 MAC addresses can be used.
●
MAC Address
Displays the MAC address of the WLAN interface.
●
Operative Channel
Shows the channel of the access point with which the client is connected.
●
HT Channel Width [MHz]
Shows the channel bandwidth.
– 20
Channel bandwidth 20 MHz.
– 40 up
Channel bandwidth 40 MHz. The configured channel and the neighboring channel
above it are used.
– 40 down
Channel bandwidth 40 MHz. The configured channel and the neighboring channel
below it are used.
Note
Channel bandwidth 40 MHz and frequency band 2.4 GHz
If the access point detects another access point on the configured channel or on
neighboring cha
nnels, the access point changes the channel bandwidth from 40 MHz
to 20 MHz. If you set a "free" channel on the access point, the access point uses the
channel bandwidth 40 MHz.
●
Connected BSSID
Shows the MAC address of the access point with which the client is connected.
●
Connected SSID
Shows the SSID of the access point with which the client is connected.
