Redundancy connection
You need the following components to make the redundancy connection, depending on the
distance to be bridged:
Maximum
distance
Required components Connection
100 m
● Crossover network cable
● Per server: A free network connection
(see section "Network components (Page 56)")
Ethernet connection
1000 m Fiber-optic cable
Per server:
● A free network connection
(see section "Network components (Page 56)")
● 1 Ethernet cable
● 1 media converter (e.g., SCALANCE X101-1)
Ethernet connection
Note
When a redundant server pair is used as an OS server and BATCH server, the redundancy
connection must be configured via the Ethernet connection.
Serial linking of the BATCH server pair is not possible in PCS 7.
Availability
The following two block diagrams of fully operational systems illustrates the availability of the
BATCH clients and BATCH servers. All BATCH components form an independent redundancy
node since they are redundant. This ensures the independence of the subsystem.
Note
Only the BATCH components and the terminal bus are shown in the block diagrams. The
terminal bus marked with * can be configured redundantly with switch modules.
%$7&+
FOLHQW
%$7&+
VHUYHU
%$7&+
VHUYHU
%XV
%$7&+
FOLHQW
The communication between BATCH clients and BATCH servers is performed over the
terminal bus.
High availability solutions in PCS 7
4.7 Solutions for SIMATIC BATCH
High Availability Process Control Systems (V9.0)
100 Function Manual, 05/2017, A5E39221836-AA
