Detailed descriptions
16.5 BIOS Setup
SIMATIC Rack PC 840 V2
Operating Instructions, Edition 05/2006, A5E00248055-04
16-37
"PCI IRQ line" field
3KRHQL[%,266HWXS8WLOLW\
(6& ([LW
6HOHFW,WHP
6HOHFW0HQX

6HOHFW
&KDQJH9DOXHV
6XE0HQX
)
)
6HWXS'HIDXOWV
6DYHDQG([LW
(QWHU
+HOS
)
0DLQ $GYDQFHG
3&,&RQILJXUDWLRQ
'LVDEOHG
$XWR6HOHFW










3&,'HYLFH6ORW
3&,'HYLFH6ORW
3&,'HYLFH6ORW
3&,'HYLFH6ORW
,545HVRXUFH([FOXVLRQ
3&,,54OLQH
3&,,54OLQH
3&,,54OLQH
3&,,54OLQH
,WHP6SHFLILF+HOS
3&,'HYLFH6ORW
3&,'HYLFH6ORW
3&,'HYLFH6ORW
Figure 16-17 The PCI IRQ line field
Disabled No interrupt possible for the selected PCI IRQ channel
AutoSelect Plug and Play mechanism in BIOS selects unassigned interrupts and allocates them
to the on-board PCI devices.
3 to 15 The selected PCI IRQ channel is assigned permanently to the selected interrupt.
You should only select this setting if this is specified in the documentation for your
application.
Assignment of the PCI IRQ channels to the PCI slots.
Rack PC 840 PCI modules interrupt assignment (PCI IRQ) in:
Module
interrupt
(Pin No.)
Slot 1 Slot 2 Slot 3 Slot 4 Slot 5 Slot 6 Slot 8
INT - A (A6) channel 1 channel 2 channel 3 channel 4 channel 1 channel 2 channel 3
INT - B (B7) channel 2 channel 3 channel 4 channel 1 channel 2 channel 3 channel 4
INT - C (A7) channel 3 channel 4 channel 1 channel 2 channel 3 channel 4 channel 1
INT - D (B8) channel 4 channel 1 channel 2 channel 3 channel 4 channel 1 channel 2
Bold letters indicate the master interrupt of the slot module
