Application planning
6.3 Configuration versions
S7-1500R/H redundant system
170 System Manual, 01/2024, A5E41814787-AF
S7-1500H configuration with R1 devices in a combined topology
Two fiber-optic cables (redundancy connections)
IO device ET 200SP HA (with system redundancy R1)
IO device ET 200SP (with system redundancy R1)
Figure 6-28 S7-1500H configuration with R1 devices in a combined topology
