9.6 Configuring R-CPUs with communications processors
S7-1500R/H redundant system
304 System Manual, 01/2024, A5E41814787-AF
9.6 Configuring R-CPUs with communications processors
Introduction
The following section guides you step by step through the configuration of the R-CPUs with
the CP 1543-1 communications processors.
Note
Configuring CP 1543
-1 communications processors with H-CPUs
You can find the procedure for configuring the H
-CPUs with the CP 1543-1 in the Active
backplane bus (
https://support.industry.siemens.com/cs/de/de/view/109778694/en)
Equipment Manual.
Requirement
The configuration detailed assumes that:
• R-CPUs have been configured. For more information, refer to the section Configuring
R/H CPUs (Page 289).
Configuring CP 1543-1 communications processors
Proceed as follows to create the CPs in the redundant system:
1. Open the R-CPUs in the device view.
