Programming
Fail-Safe Systems
5-66 A5E00085588-03
5.4.14 Saving reference data
You can save all the data of a program (charts, parameters, etc.) as reference data
in order to use it for comparisons, as required.
Procedure
To save the reference data of a Safety Program, proceed as follows:
1. Select the program folder (e.g. "S7 Program") in SIMATIC Manager.
2. Choose the Options > Edit Safety Program menu command. The "Safety
Program – S7 Program" dialog box appears.
3. Click the "Save Reference" button. You will then be asked again if you want to
save the reference data. You have two options:
- Confirm with "Yes" if you want all the information on the blocks of the
current project to be saved as reference information. Any existing
reference data will be overwritten.
- Cancel with "No" if you do not want to save reference data.
