Fail-Safe Blocks
Fail-Safe Systems
8-122 A5E00085588-03
8.13.8 F_MIN3_R
Function
This block compares three inputs and then outputs the minimum value at the
output. All the inputs are preset with a value of 3,402823e+38 (largest positive
REAL number), so that even a minimum value can be formed from only two inputs.
OUT = MIN {IN1, IN2, IN3}
I/Os
Name Data Type Explanation Default
Inputs:
IN1 F_REAL Input variable 1 3.402823e+38
IN2 F_REAL Input variable 2 3.402823e+38
IN3 F_REAL Input variable 3 3.402823e+38
Output:
OUT F_REAL Minimum value 3.402823e+38
Error Handling
If the operation generates an invalid REAL number the event will be recorded in
the Diagnostic Buffer.
Error Information in Diagnostic Buffer
Error Code (W#16#...) Description
75D9H
Invalid REAL number generated by the operation.
