Fail-Safe Blocks
Fail-Safe Systems
A5E00085588-03
8-51
8.5.3 F_S_R
Function
This block safely transfers 5 data items of the data type F_REAL to another F-run-
time group. It can be received there by the F_R_R block.
The data to be sent (e.g. outputs from other blocks) is stored at the inputs
SD_R_xx.
The output S_DB must be connected with the input of the same name in the
received block.
I/Os
Name Data Type Explanation Default
Inputs:
SD_R_00 F_REAL Send date 00 0
... ...
SD_R_04 F_REAL Send data 04 0
Output:
S_DB F_WORD Separate instance DB no. 0
Error Handling
None
