Fail-Safe Blocks
Fail-Safe Systems
8-42 A5E00085588-03
8.4.7 F_FR_R
Function
This block converts the F-data type F_REAL into the standard data type REAL,
since individual structure elements of the F-data type cannot be accessed
separately in the CFC chart. This enables signals formed in the Safety Program
section to be further processed in the standard program section.
This block must be placed in the standard program section.
I/Os
Name Data Type Explanation Default
Input:
IN F_REAL Input variable 0.0
Output:
OUT REAL Output variable 0.0
Error Handling
None
