Getting Started
Fail-Safe Systems
A5E00085588-03
2-3
You will then be able to configure a fault-tolerant F-system.
Sample Projects Provided
Note
The sample projects require Step 7 V5.2 and the S7 H Systems Optional Package
Version 5.1.
You can find two sample projects in step7\Examples:
• ZEN32 01_FSystem_Fproj – For an F System
• ZEN32 02_FHSystem_FHProj – For a fault-tolerant FH System
You can use the examples to check the results of similar project sessions
described below.
Passwords
The passwords for the projects provided are:
• CPU password: anna
• Safety Program password: otto
