Welcome to the SIMATIC Rack PC IL 40 S
2-6
SIMATIC Rack PC IL 40 SManual
A5E00200171-01
9 USB
Connectors for Universal Serial Bus (high current, high speed USB 2.0). You can
use the USB port to connect external devices, for example, CD drives, printers,
modems as well as mouse and keyboard. Older operating systems such as
Windows NT do not support this port.
10 Microphone input
Audio connector for connecting a microphone.
11 Audio output
Audio connector for connecting earphoness.
12 Audio input
Audio connector for connecting a linear audio source.
13Ć14 Expansion Slots
Internal slots for expansion modules. Six PCI slots 14 and an AGP slot 13 are
available.
15 Type Label
You can find the order number and the serial number (S VP) of your device on the
type label, as well as a list of country-specific security certifications.
16 Serial/COM 2 (optional)
The serial port 2 (V.24) is used to connect serial port devices such as modem,
mouse or printer.
17 Dummy Panel
Enables the installation of external ports.
18 Fan openings
Enables you to install a 60-mm fan later.

Siemens Simatic series Specifications

General

Processor	Intel Core i3, Core i5, Core i7
Operating System	Windows 10 IoT Enterprise, Linux
Storage	SSD, HDD
Interfaces	Ethernet, USB, RS-232/485
Ports	Ethernet, USB, Serial
Mounting	DIN rail, wall
Protection Class	IP65
Graphics	Integrated Intel HD Graphics
Expansion Slots	PCIe
Power Supply	24V DC or 100-240V AC
Operating Temperature	0°C to 50°C (depending on model)
