7.1 Current Requirement of the Components (Maximum
Values)
Basic System
Component Voltage
+5V +3.3V +12V –12V 5Vaux
Motherboard FSC1527 with
Intel Pentium 4 Processor 2.4 GHz /
Intel Celeron Processor 2 GHz
0.9 A 3.4 A 8 A 0.05 A
Floppy disk drive 0.25 A
Hard drive EIDE 0.5 A 0.4 A
CD ROM drive 0.9 A 0.8 A
CD RW drive 0.9 A 0.8 A
Raid controller 0.5 A
Front fan 0.5 A
Single lines of current (max. permissible)
1)
20 A 18 A 18 A 1 A 2 A
Total power consumption, permissible 180 W
Power efficency of the power supply  68% (230VAC) /  65% (115VAC)
*1
Depending on the selected device configuration
*2
The total power comsumption of the +3.3V / +5V voltages from 135W has to be monitored
