SIMATIC Rack PC IL 40 S Expansions
4-13
SIMATIC Rack PC IL 40 SManual
A5E00200171-01
4. Remove the drive supports on the side (3) only when necessary, for example to
fit a drive in the front drive support (1).
5. Undo the six screws (2) to remove the drive support on the side (3).
6. Note down the cable assignment and remove the cables.
7. Proceed in reverse order when installing the drive holder.
1
3
2
2
Figure 4-9 Uninstalling the drive support module
Hard disk drives can be installed in a removable rack.
