Siemens Simatic series Manual

Retrofit Notes
C-2
SIMATIC Rack PC IL 40 SManual
A5E00200171-01
Permissible Variants of Equipment for the Temperature Range of 5 to 35_C
CD-ROM / CD-R/RW
HD in removable rack
Floppy
CD-ROM
CD-ROM / CD-R/RW
HD in removable rack
Figure C-1 Permissible Variants of Equipment for the Temperature Range of 5 to 35 C
Celeron and P4 processors up to 2.4 Ghz can be used. The maximum permissible
power loss of expansion modules is 90W.
In the place of CD-ROM/CD-R/RW, you can install removable racks with hard disk
drives.
Devices equipped with removable racks are not to be exposed to shock in
accordance with DIN IEC 600068-2-29.
Permissible Variants of Equipment for the Temperature Range of 5 to 40_C
CD-ROM
HD in removable rack
Floppy
CD-ROM
CD-ROM
HD in removable rack
Figure C-2 Permissible Variants of Equipment for the Temperature Range of 5 to 40 C
Celeron and P4 processors up to 2.4 Ghz can be used. The maximum permissible
power loss of expansion modules is 90W.
In the place of CD-ROM, you can install removable racks with hard disk drives.
Devices equipped with removable racks are not to be exposed to shock in
accordance with DIN IEC 600068-2-29.

Siemens Simatic series Specifications

General

Processor	Intel Core i3, Core i5, Core i7
Operating System	Windows 10 IoT Enterprise, Linux
Storage	SSD, HDD
Interfaces	Ethernet, USB, RS-232/485
Ports	Ethernet, USB, Serial
Mounting	DIN rail, wall
Protection Class	IP65
Graphics	Integrated Intel HD Graphics
Expansion Slots	PCIe
Power Supply	24V DC or 100-240V AC
Operating Temperature	0°C to 50°C (depending on model)
