Siemens SIMATIC TDC User Manual

Signal modules
5.1 SM500 signal module
SIMATIC TDC hardware
120 System Manual, 08/2017, A5E01114865-AL
Voltage, currents
Rated voltages at 25 °C
Typical current consumption
+5 V
1 A
+3.3 V
50 mA
+12 V
300 mA
-12 V 300 mA
Power losses/fan
Typical power losses
12.5 W
Fan required
yes
Dimensions
Number of slots required in the rack
1
Dimensions W x H x D [mm]
20 x 233 x 160
Weight, approx.
0.7 kg
