Interface module
7.2 Interface module SB60
SIMATIC TDC hardware
184 System Manual, 08/2017, A5E01114865-AL
7.2.1
Signals
Signals up to a maximum of 120 V (nominal value) DC or AC can be connected at the SB60
interface module.
Yellow LED
The status of the binary interface module outputs (binary inputs for SIMATIC TDC) is
indicated using yellow LEDs (1...8).
Terminal block X2 provides two screw terminals for each signal:
terminals 12, 22, ... up to 82 for binary signals 120 V
terminals 11, 21, ... up to 81 for the reference point
Note
When wiring the signal lines to the terminals, observe “Installation and EMC Directives” in
the User Manual.
7.2.2
Application notes
The interface module is designed
only for vertical mounting positions
due to thermal losses
to be dissipated.
Other information
For more information on EMC and environmental conditions, refer to section "General
technical specifications (Page 37)"!
