Communication modules
6.6 CP53M0 coupling module
SIMATIC TDC hardware
172 System Manual, 08/2017, A5E01114865-AL
Figure 6-19 Connection options of CP53M0
Additional components
Fiber-optic cable (FOC)
The following cable is used to connect communication module CP53M0 to an additional
CP53M0, or to a CS12/CS13/CS14/CS22:
SIMATIC NET, STANDARD FIBER-OPTIC CABLE, SPLITTABLE, DRESSED WITH 4 x
BFOC CONNECTORS
Article number: 6XV1820-5Bxyz (xyz: length code)
For information on available lengths, refer to the interactive catalog in the A&D MALL.
