Siemens SIMATIC TDC - Additional Components; Pin Assignments

Communication modules
6.2 CP51M1 communication module
SIMATIC TDC hardware
134 System Manual, 08/2017, A5E01114865-AL
6.2.6
Additional components
Connecting cables
Designation
Article number
SIMATIC NET, Industrial Ethernet TP XP CORD
RJ45/RJ45, dressed with 2 x RJ45 connectors, length ...
6XV1870-3R...
You can find more information in the SIMATIC NET Catalog IK PI or in the Siemens Industry
Mall (https://mall.industry.siemens.com).
For more information on networks and their cabling, refer to the following documentation:
● Industrial Ethernet/PROFINET
Passive Network Components system manual
(http://support.automation.siemens.com/WW/view/de/84922825/0/en)
● Industrial Ethernet/PROFINET
Industrial Ethernet system manual
(http://support.automation.siemens.com/WW/view/de/27069465/0/en)
6.2.7
Pin assignments
Industrial Ethernet interface X1, 10/100 Mbps TP(RJ-45 jack)
Table 6- 8 Pin assignment of X1 (RJ-45 jack)
PIN
Designation
1 TX+
2
TX -
3
RX+
4
75 ohm termination
5
75 ohm termination
6
RX-
7
75 ohm termination
8
75 ohm termination
Enclosure
Shield
