Interface module
7.2 Interface module SB60
SIMATIC TDC hardware
186 System Manual, 08/2017, A5E01114865-AL
7.2.4
Pin assignment
Flat connector X1
The cables SC62 or SC66 are used to connect the interface modules to the SIMATIC TDC
components (for more information, refer to the SIMATIC TDC Documentation).
Digital inputs terminal block X2
Table 7- 2 Pin assignment of the digital inputs of interface module SB60
Terminal
120 V
Channel No.
11
21
31
41
51
61
71
81
Reference
Reference
Reference
Reference
Reference
Reference
Reference
Reference
Channel 1
Channel 2
Channel 3
Channel 4
Channel 5
Channel 6
Channel 7
Channel 8
12
22
32
42
52
62
72
82
120 V input
120 V input
120 V input
120 V input
120 V input
120 V input
120 V input
120 V input
Channel 1
Channel 2
Channel 3
Channel 4
Channel 5
Channel 6
Channel 7
Channel 8
14
24
34
44
54
64
74
84
n.c.
n.c.
n.c.
n.c.
n.c.
n.c.
n.c.
n.c.
Channel 1
Channel 2
Channel 3
Channel 4
Channel 5
Channel 6
Channel 7
Channel 8
Conductor cross-section
The minimum conductor cross-section for the terminal block X1 is 0.2mm² and the maximum
is 2.5 mm².
