5.1 SM500 signal module
SIMATIC TDC hardware
110 System Manual, 08/2017, A5E01114865-AL
5.1.8
Pin assignments
Connection X1 with cable SC63
The assignment of the screw terminals at interface module SU13 corresponds to the
connector assignment of X1.
Table 5- 5 Pin assignment of X1
X1
Designation
SU13
X1
Designation
SU13
1
Analog output 1+
1
26
Analog output 5+
26
2 Analog output 1 - 2 27 Analog output 5 - 27
3
Analog output 2+
3
28
Analog output 6+
28
4 Analog output 2 - 4 29 Analog output 6 - 29
5
Analog output 3+
5
30
Analog output 7+
30
6
Analog output 3 -
6
31
Analog output 7 -
31
7
Analog output 4+
7
32
Analog output 8+
32
8
Analog output 4 -
8
33
Analog output 8 -
33
9
-
9
34
-
34
10
Ground, DA converter
10
35
Ground, DA converter
35
11
Analog input 1 +
11
36
Analog input 5 +
36
12
Analog input 1 -
12
37
Analog input 5 -
37
13
Analog input 2+
13
38
Analog input 6+
38
14
Analog input 2 -
14
39
Analog input 6 -
39
15
Analog input 3+
15
40
Analog input 7+
40
16
Analog input 3 -
16
41
Analog input 7 -
41
17
Analog input 4+
17
42
Analog input 8 +
42
18
Analog input 4 -
18
43
Analog input 8 -
43
19
-
19
44
-
44
20
Ground, AD converter
20
45
Ground, AD converter
45
21 Integrating analog input 1+ 21 46 Integrating analog input 3 + 46
22
Integrating analog input 1-
22
47
Integrating analog input 3 -
47
23
Integrating analog input 2 +
23
48
Integrating analog input 4 +
48
24
Integrating analog input 2 -
24
49
Integrating analog input 4 -
49
25
Ground, analog input
25
50
Ground, analog input
50
