Rack
3.3 Rack UR5213 (6DD1682-0CH0)
SIMATIC TDC hardware
68 System Manual, 08/2017, A5E01114865-AL
3.3.4
Status and fault displays
Table 3- 4 Status displays for UR5213
LED
Display
Rack state
POWER
(green or red)
green is on
fault-free operation
red is on fault (refer to voltage monitoring)
FAN FAIL
(red)
Off
fault-free operation
On
fault (at least one fan has failed)
SYSFAIL
(red)
Off
fault-free operation
On
System was stopped
3.3.5
Power supply
Mains connection
Mains is connected to the 3-pin screw terminal block on the right side of the power supply
unit.
The pin assignment is printed onto the front panel.
Input voltage 90 - 264 V AC
Derating 85 – 90 V
Dielectric strength
• Mains inlet / PE
• Mains inlet / SELV
• SELV / PE
1500 V AC
3000 V AC
500 V AC
Power consumption
800 W (apparent power approx. 835 VA)
L
Phase conductor L
N
Neutral conductor N
Ground conductor PE
External fuse
(dimensioning)
In = 9 A
Is = <50 A (inrush peak)
The power supply is equipped with an internal 12 A fuse. This
means that only the mains supply has to be fused. It is recom-
mended to use a standard 16 A thermo magnetic circuit-breaker
(B characteristic).
Alternatively, a slow-acting fuse may be used.
