Rack
3.2 Rack UR5213 (6DD1682-0CH2)
SIMATIC TDC hardware
64 System Manual, 08/2017, A5E01114865-AL
Output voltages
The following lists the maximum current load on the output voltages of the rack.
Rated output voltage
Max. output current load on the module type
+5 V
36 A
+3.3 V
44 A
+12 V
4.6 A
-12 V 4 A
Total output power may not exceed 320 W. This must be ensured i your configuration.
The output currents are listed in the respective description.
The output power limit of 320 W is not exceeded even in a full assembly of the rack
consisting of the module types CPU551, SM500, CP51M1, CP50M1 and CP52A0.
Note
If using other modules, you must check the individual maximum currents and
verify the
maximum load of 320 W.
All outputs are sustained short circuit-proof and
do not
need a basic load.
Battery
Current load Approx. 20 µA for the monitoring function and
max. 180 µA for slots 1-21
Relay contacts
Rated voltage (AC)
230 V (max. 264 V)
Rated current
2 A
Dimensions
Number of rack slots
21
Dimensions W x H x D [mm]
approx. 482.6 x 354.9 x 343
Weight
Approx. 20 kg
