CPU modules
4.2 CPU module CPU550/CPU551
SIMATIC TDC hardware
98 System Manual, 08/2017, A5E01114865-AL
CPU
SDRAM / DDR2-DRAM
• During initialization, the user program is loaded from
program memory and expanded (Boot Flash is available
separately)
• Data memory for the operating system, communication,
message buffer, and Trace
32 MB 128 MB 1 GB
SRAM
Buffered SRAM (by means of external battery in the rack)
contains the following data that must be backed up to reten-
tive memory on power failure:
• Fault diagnostics of the operating system ("exception
buffer")
• Max. 993 process variables configured with
func-
tion block
• Data recorded using the Trace function or the message
system (SRAM can be optionally configured)
256 KB
512 KB 512 KB
Synchronized L2 cache
Synchronized L3 cache
2 MB 8 MB 1 MB
Allocation of the slots
• Program memory MC5xx
• PMC plug-in cards
1)
1)
PMC plug-in cards are currently not provided.
