You can 󹪝nd possible combinations in the relevant catalog.
Please note that not every theoretical combination is possible.
Description Position in the article number
1 2 3 4 5 6 7 - 8 9 1
0
11 12 - 13 14 15 16
SIMOTICS S-1FK2 synchronous servomotors 1 F K 2
Version/inertia
High Dynamic 1
Compact 2
High Inertia 3
Frame size / shaft height SH 30 0 3
SH 40 0 4
SH 48 CT
SH 52 HD
0 5
SH 63 0 6
SH 80 0 8
SH 100 1 0
Overall length 0 ... 8 -
(Not de󹪝ned) A
Rated speed 1500 r/min @ 400 V B
2000 r/min @ 400 V C
3000 r/min @ 400 V F
4500 r/min @ 400 V H
6000 r/min @ 400 V K
Holding brake None 0
with 1
Degree of protection IP64 0
IP65 with radial shaft seal ring without spring 1
Shaft geometry Plain shaft (without keyway) 0
Shaft with feather key 1
Plain shaft, alternative shaft extension
(11 mm x 23 mm), for 1FK2☐03 only
0 3 0 2
Plain shaft, alternative shaft extension
(14 mm x 30 mm), only for 1FK2☐04
0 4 0 2
Encoder Absolute encoder, singleturn, 22-bit (encoder AS22DQC) S
Absolute encoder 22-bit + 12-bit multiturn (encoder AM22DQC) M
Connection system 2CC (two cable system) for S120 B
Version number Start 0
Description of the motors
2.3 Structure of the article number
SIMOTICS S-1FK2 synchronous motors for SINAMICS S120
Operating Instructions, 02/2022, A5E46089564B AD 31
