7.2 Checklists for commissioning
Note
Required checks
The lists below do not purport to be complete. It may be necessary to perform additional checks
and tests in accordance with the situation specic to the particular installation site.
Before commissioning the system, check that it is properly installed and connected.
Commission the drive system according to the Operating Instructions of the converter or
inverter being used.
Checklists for commissioning the motors 1FK2 and 1FT2
Thoroughly familiarize yourself with the safety instructions and observe the checklists below
before starting any work.
Table 7-1 Checklist (1) - general checks
Check OK
Are all of the necessary components of the congured drive line-up available, correctly
dimensioned, installed and connected?
Is the manufacturer documentation for the system components (e.g. drive system, brake)
available?
Is the motor type to be commissioned known?
(e.g. 1FK2 _ _ _ – _ _ _ _ _ – _ _ _ _)
Are the ambient conditions in the permissible range?
Table 7-2 Checklist (2) - checks regarding the mechanical system
Check OK
Have all touch protection measures for moving and live parts been tted and are they
functional?
Has the motor been correctly mounted and aligned?
Can you rotate the rotor without it touching the stator?
Have all xing screws, connecting elements, and electrical connections been tightened
with the prescribed torques and properly attached?
Do the operating conditions correspond to the data specied on the rating plate?
Do the output elements have the correct setting conditions according to type?
Examples:
• Have the couplings been aligned and balanced?
• Has the belt drive tension been correctly adjusted?
• Have the gear tooth ank and gear tooth tip play as well as radial play been correctly
adjusted for geared outputs?
Commissioning
7.2 Checklists for commissioning
SIMOTICS S-1FK2 synchronous motors for SINAMICS S120
84 Operating Instructions, 02/2022, A5E46089564B AD
