Table 7-3 Checklist (3) - checks regarding the electrical system
Check OK
Has the motor been connected so that it rotates in the speci󹪝ed direction?
Have the minimum insulation resistance values been maintained?
Have the grounding and equipotential bonding connections been correctly established?
Is the speci󹪝ed limit speed n
max
maintained during the operation on the converter?
Table 7-4 Checklist (4) - Monitoring equipment checks
Check OK
Has it been ensured that speeds higher than the maximum speed n
max
cannot be reached?
Have all supplementary motor monitoring devices been correctly connected and are they
working properly?
Table 7-5 Checklist (5) - Cooling system checks
Check OK
Natural cooling
Have you adapted the torque and power of the motor to the ambient conditions?
You will 󹪝nd information on the derating in the con󹪝guration manual.
Observe the information provided in the converter operating instructions.
Table 7-6 Checklist (6) - Checks regarding the optional brake
Check OK
Is the brake open when the operating voltage is applied?
Does the brake open and close correctly?
Commissioning
7.2 Checklists for commissioning
SIMOTICS S-1FK2 synchronous motors for SINAMICS S120
Operating Instructions, 02/2022, A5E46089564B AD 85
